W20959_Full – Uncapping and honey extraction line

PC-02 control unit: LCD display; knife temperature adjustment; emergency button for immediate stop of the knives; 2. Cappings press, 200 kg/h. Capacity 100 kg per hour. Adjustable rotation speed and direction. Adjustable motor speed, max. 9 rpm. Motor 0.55 kW. 3. Manual frame feeding unit. Mechanical drive. Length 2100 mm. Lever that locks the honey extractor basket. 4. Horizontal strainer with pump. Stainless steel filters. Strainer with electric heating. The strainer is fitted with a honey level sensor. Strainer capacity approx. 120 L. Pump connected to the strainer (hoses included). Pump capacity 900 L/h. Strainer cover included. 5. Horizontal honey extractor. 2-section basket for frames. Honey extractor capacity from 40 frames (2 sections). Honey extractor throughput up to 400 kg/h. HE-03 control unit: • • intuitive interface; • 4.3″ colour display; • 7 automatic programs; • 2 manual programs; • the screen shows the stages of the extraction process; • ability to program your own extraction cycle; 6. Double storage unit for extracted frames. HE-03 control unit. Module that adjusts the drum position. 2 sections for extracted frames. Capacity up to 80 frames, depending on type. Easy position adjustment relative to the honey extractor. Length 1500 mm. 7. Storage unit for extracted frames. Honey extractor drum lock. HE-03 control unit Capacity up to 40 frames, depending on type. Easy position adjustment relative to the honey extractor. Length 1500 mm.
